| Ref |
Part Number |
Description |
Qty Req |
|
| 1 |
42305-NX4-000 |
COLLAR, CALIPER BRACKET |
1 |
Buy Now! |
| 2 |
43100-NF5-612 |
CALIPER ASSY, REAR |
1 |
Buy Now! |
| 3 |
43105-NF5-612 |
PAD COMP, REAR BRAKE |
2 |
Buy Now! |
| 4 |
43109-MA3-006 |
SEAL, DUST |
1 |
Buy Now! |
| 5 |
43111-NX4-000 |
ROD, REAR BRAKE TORQUE |
1 |
Buy Now! |
| 6 |
43209-MA3-006 |
DUST-SEAL, PISTON |
1 |
Buy Now! |
| 7 |
43352-568-003 |
SCREW, BLEEDER |
1 |
Buy Now! |
| 8 |
43353-461-771 |
CAP, BLEEDER |
1 |
Buy Now! |
| 9 |
45107-GM9-711 |
PISTON |
1 |
Buy Now! |
| 10 |
45108-GM9-741 |
SPRING, BRAKE PAD |
1 |
Buy Now! |
| 11 |
45131-166-016 |
PIN, BOLT |
1 |
Buy Now! |
| 12 |
45131-HA5-672 |
PIN, BOLT A |
1 |
Buy Now! |
| 13 |
45132-166-016 |
PIN, BUSH |
1 |
Buy Now! |
| 14 |
45133-MA3-006 |
BOOT B |
1 |
Buy Now! |
| 15 |
45203-MG3-016 |
PIN, PLUG |
2 |
Buy Now! |
| 16 |
45215-GE2-016 |
PIN, HANGER |
2 |
Buy Now! |
| 17 |
90475-425-000 |
WASHER, THRUST 30mm |
1 |
Buy Now! |
| 18 |
90485-GB4-790 |
WASHER 8mm |
2 |
Buy Now! |
| 19 |
91048-NX4-710 |
ROD END 8mm |
2 |
Buy Now! |
| 20 |
94002-08000-0S |
NUT, HEX (8mm) |
2 |
Buy Now! |
| 21 |
94050-08000 |
NUT, FLANGE (8mm) |
2 |
Buy Now! |
| 22 |
94102-08000 |
WASHER, PLAIN (8mm) |
2 |
Buy Now! |
| 23 |
94510-30000 |
CIRCLIP, EXTERNAL (30mm) |
1 |
Buy Now! |
| 24 |
95801-08035-00 |
BOLT, FLANGE (8x35) |
1 |
Buy Now! |
| 25 |
95801-08045-00 |
BOLT, FLANGE (8x45) |
1 |
Buy Now! |
|
|
|
